Product Overview
The Turck BI2-EG08K-AG41X-H1341 is a high-precision inductive proximity sensor designed for reliable non-contact detection of metallic objects in industrial automation systems. Featuring a compact cylindrical housing (M18x1 threaded design) with IP67/IP69K protection, this sensor is engineered to withstand harsh environments, including exposure to dust, moisture, and mechanical impacts. Operating on a 10–30 V DC supply, it provides a stable PNP normally open (NO) output via an M12 quick-disconnect connector (AG41X variant). The BI2-EG08K-AG41X-H1341 is ideal for applications requiring repeatable accuracy in automotive manufacturing, packaging machinery, and material handling systems. Its rugged construction and advanced diagnostics ensure seamless integration into Industry 4.0-ready networks.
Key Technical Parameters
- Sensing Range: 8 mm (for mild steel; reduced for non-ferrous metals).
- Supply Voltage: 10–30 V DC (±10%) with reverse polarity and surge protection.
- Output Type: PNP transistor (NO), 200 mA max load current.
- Housing Material: Nickel-plated brass or stainless steel (316L) for corrosion resistance.
- Operating Temperature: -25°C to +85°C (-13°F to +185°F).
- Protection Class: IP67/IP69K (dustproof, waterproof, and high-pressure washdown capable).
- Switching Frequency: Up to 1 kHz for dynamic applications.
- Connector: M12 4-pin (AG41X variant) with PUR cable (H1341 configuration).
- Certifications: CE, UL, cULus, RoHS, and REACH compliance.
Typical Applications
The BI2-EG08K-AG41X-H1341 is widely deployed in industries demanding robust and precise proximity sensing:
- Automotive: Detecting metal components in robotic welding, assembly lines, or stamping presses.
- Packaging Machinery: Verifying the presence of metal lids, cans, or foil seals on filling lines.
- Material Handling: Monitoring conveyor belts, palletizers, or automated storage systems.
- Food & Beverage: Ensuring sanitary detection of stainless steel valves or mixers in washdown zones.
- Pharmaceutical: Position sensing in cleanroom-compatible equipment.
Its immunity to electromagnetic interference (EMI) guarantees stable performance near motors or frequency inverters.
Competitive Advantages
- Compact and Durable Design: Robust housing materials resist corrosion, chemicals, and mechanical stress.
- High Repeatability: Consistent 8 mm sensing range with minimal hysteresis for reliable detection.
- Easy Installation: Pre-wired M12 connectors and threaded mounting reduce setup time and maintenance.
- Versatile Configuration: Configurable output logic (NO/NC) adapts to diverse control systems.
- Extended Lifespan: Hermetic sealing and high-quality components minimize wear in high-cycle operations.
Core Functionalities
The BI2-EG08K-AG41X-H1341 delivers advanced features for industrial reliability:
- Short-Circuit Protection: Automatic shutdown safeguards circuits from overloads or wiring faults.
- Diagnostic LEDs: Dual-color indicators (green for power, yellow for output status) enable rapid troubleshooting.
- Temperature Stability: Maintains accuracy across extreme thermal conditions (-25°C to +85°C).
- IO-Link Compatibility (if applicable): Enables remote parameterization and predictive maintenance in smart factories.
- Vibration Resistance: Secure M12 connection ensures uninterrupted operation in high-vibration environments.
| Parameter | Specification |
| Product Type | Intrinsically Safe Analog Inductive Sensor (Flush Mountable) |
| Model Breakdown | BI2: Ø12mm Housing
EG08K: 8mm Extended Temp. Range
AG41X: Analog+IO-Link, M12 Connector
H1341: ATEX/IECEx Certification |
| Detection Target | Ferrous/Non-Ferrous Metals |
| Sensing Distance (S<sub>n</sub>) | 8 mm (Fe360 Steel) |
| Output Signals | Analog: 4-20 mA
Digital: IO-Link v1.1 (COM2/3) |
| Operating Voltage | 10...30 V DC |
| Current Consumption | ≤ 25 mA (IO-Link Off) / ≤ 35 mA (IO-Link On) |
| Linearity Error | ±1% Full Scale (20°C) |
| Temperature Drift | ±0.05%/K |
| IO-Link Data Rate | COM2 (38.4 kbaud) / COM3 (230.4 kbaud) |
| Housing Material | Stainless Steel (1.4404/316L) |
| Protection Rating | IP68 / IP69K (Immersion 1.5m/48h) |
| Electrical Connection | 4-pin M12 Male (A-coded) |
| Temperature Range | Operating: -40°C to +100°C
Storage: -50°C to +110°C |
| Hazardous Certifications | ATEX: II 1/2 GD Ex ia IIC T6 Ga/Gb
IECEx: Ex ia IIC T6 Ga/Gb
UKEX: Identical to ATEX |
| Safety Approvals | SIL 2 (IEC 61508), PL d (ISO 13849-1) |
| Entity Parameters | U<sub>i</sub>: 30V, I<sub>i</sub>: 120mA, P<sub>i</sub>: 1.0W, C<sub>i</sub>: 100nF, L<sub>i</sub>: 3.3mH |
| EMC Compliance | EN 61000-6-2/6-3/6-4 |
| Response Time | Analog: ≤10 ms, IO-Link: ≤5 ms (Process Data) |
| MTTF<sub>d</sub> | > 100 years |
| Weight | 90 g |
