Product Overview
The Turck BI8-M18-VP4X2-H1141 is a rugged inductive proximity sensor designed for precise non-contact detection of metallic objects in demanding industrial environments. Featuring an M18 stainless steel housing with IP67/IP69K protection, this sensor is engineered to withstand harsh conditions such as dust, moisture, mechanical shocks, and high-pressure washdowns. Operating on a 10–30 V DC supply, it delivers a configurable PNP or NPN output via a shielded M12 connector (VP4X2 variant). The BI8-M18-VP4X2-H1141 is optimized for applications requiring repeatable accuracy and durability, such as automotive manufacturing, material handling, and food processing. Its compact design and advanced diagnostics ensure seamless integration into Industry 4.0-ready automation networks.
Key Technical Parameters
- Sensing Range: 8 mm (for mild steel; reduced for non-ferrous metals).
- Supply Voltage: 10–30 V DC (±10%) with reverse polarity and surge protection.
- Output Type: Configurable PNP/NPN transistor (NO/NC), 200 mA max load current.
- Housing Material: Stainless steel (316L) with anti-corrosion coating.
- Operating Temperature: -25°C to +85°C (-13°F to +185°F).
- Protection Class: IP67/IP69K (dustproof, waterproof, and high-pressure resistant).
- Switching Frequency: Up to 1 kHz for rapid response in dynamic applications.
- Connector: M12 4-pin shielded (VP4X2 variant) with PUR cable (H1141 configuration).
- Certifications: CE, UL, cULus, RoHS, and REACH compliance.
Typical Applications
The BI8-M18-VP4X2-H1141 excels in industrial automation scenarios requiring robust sensing solutions:
- Automotive Assembly: Detecting metal components in robotic welding, stamping presses, or conveyor systems.
- Packaging Machinery: Verifying the presence of metal lids, cans, or foil seals on high-speed filling lines.
- Food & Beverage: Monitoring stainless steel valves, mixers, or conveyor chains in sanitary washdown zones.
- Material Handling: Position feedback for automated guided vehicles (AGVs) or palletizing systems.
- Heavy Machinery: Ensuring safety interlocks for hydraulic cylinders or rotating equipment.
Its immunity to electromagnetic interference (EMI) guarantees stable performance near motors, inverters, or welding systems.
Competitive Advantages
- Extreme Durability: 316L stainless steel housing resists corrosion, chemicals, and mechanical stress.
- High Sensing Accuracy: Consistent 8 mm range with minimal hysteresis for reliable detection of small or thin targets.
- Quick Installation: Pre-wired M12 connectors and threaded design minimize setup time and maintenance.
- Flexible Configuration: Configurable output logic (PNP/NPN) adapts to diverse control systems.
- Long Lifespan: Hermetic sealing and robust construction reduce downtime in high-cycle operations.
Core Functionalities
The BI8-M18-VP4X2-H1141 delivers advanced features for industrial reliability:
- Short-Circuit Protection: Automatic shutdown safeguards against wiring faults or overloads.
- Diagnostic LEDs: Dual-color indicators (green for power, yellow for output status) enable rapid troubleshooting.
- Temperature Stability: Maintains performance across extreme thermal conditions.
- IO-Link Compatibility (if applicable): Enables remote parameterization, diagnostics, and firmware updates.
- Vibration Resistance: Secure M12 connection ensures uninterrupted operation in high-vibration environments.
| Parameter | Specification |
| Product Type | Analog Inductive Sensor (Non-Flush Mount) with Dual Output |
| Model Breakdown | NI75U: Ø75mm Housing
CP80: 40mm Sensing Distance (Factor 2)
AP6X2: Analog 4-20mA + 0-10V, 2m Cable |
| Detection Target | Ferrous Metals (Optimized) / Non-Ferrous (Derated) |
| Sensing Distance (S<sub>n</sub>) | 40 mm (Fe360 Steel) |
| Effective Range | 0-80 mm (Linear Analog Range) |
| Reduction Factor | 1.0 (Steel) / 0.6 (304 SS) / 0.4 (Aluminum) |
| Output Signals | Analog Current: 4-20 mA
Analog Voltage: 0-10 V (Simultaneous) |
| Operating Voltage | 15...30 V DC |
| Current Consumption | ≤ 35 mA (No Load) |
| Load Impedance | Current: ≤ 500 Ω
Voltage: ≥ 10 kΩ |
| Linearity Error | ±1% Full Scale (20°C) |
| Repeat Accuracy | ≤ 0.1% Full Scale |
| Temperature Drift | ±0.03%/K |
| Response Time | ≤ 5 ms |
| Housing Material | 316L Stainless Steel (Corrosion-Resistant) |
| Protection Rating | IP68 / IP69K (Immersion 5m/48h, 150°C Steam Clean) |
| Electrical Connection | Fixed 2m PUR Cable (Ø8mm, Blue Jacket) + 5-pin M12 Internal Socket |
| LED Indicators | Tri-color: Power (Green), Output Active (Yellow), Fault (Red) |
| Temperature Range | Operating: -40°C to +85°C
Storage: -50°C to +100°C |
| Shock/Vibration | Shock: 100 g (6 ms, IEC 60068-2-27)
Vibration: 10 g (10...500 Hz, IEC 60068-2-6) |
| EMC Compliance | EN 61000-6-2 (Immunity), EN 61000-6-4 (Emissions) |
| Certifications | ATEX II 3G Ex nA nC IIC T6 Gc
IECEx Ex nA nC IIC T6 Gc
cULus, CE, SIL 3 |
| Reverse Polarity Protection | Yes |
| Short-Circuit Protection | Auto-Reset (Current Output) |
| Weight | 1.2 kg |
| Housing Thread | M75×1.5 |
| Mounting | Non-Flush (Requires 2×S<sub>n</sub> Clearance) |
